SQN71.664A20 SIEMENS Servo Motor Damper Actuators
Roll over image to zoom in
৳ 19,500.00
Electromotoric actuators Siemens SQN71.664A20 for air dampers and valves of oil or gas burners of small to medium capacity.
Rotation: Clockwise.
Running time: 30 sec for 90º at 50 Hz.
Nominal torque: 2.5 Nm.
Power supply: AC 230 V 50/60 Hz.
The actuators are used primarily for controlling the volume of fuel and combustion air:
- Load-dependent in connection with P-PI or PID controllers, such as the RWF40...
- Directly with the help of the different types of burner controls, such as the LOA..., LMO..., LMG... or LFL..
Electromotoric actuators Siemens SQN71.664A20 for air dampers and valves of oil or gas burners of small to medium capacity.
Rotation: Clockwise.
Running time: 30 sec for 90º at 50 Hz.
Nominal torque: 2.5 Nm.
Power supply: AC 230 V 50/60 Hz.
The actuators are used primarily for controlling the volume of fuel and combustion air:
– Load-dependent in connection with P-PI or PID controllers, such as the RWF40…
– Directly with the help of the different types of burner controls, such as the LOA…, LMO…, LMG… or LFL..
