ECO WATER FLOW METER 4 INCH FLANGE TYPE
৳ 18,500.00৳ 19,500.00 (-5%)
4" Flanged Threaded Water Meter
Connection:- 4" flange (100mm)
Body:- Coated cast iron case and head
Turbine:- Non-hygroscopic and antimagnetic
Constant / K Factor:- K = 1000.0 (1 pulse per 1000.0 Litres)
Contacting Head Output:- Reed Switch rated at 5 VA
Start Flow:- 2.0m3 / Hr
Max Temporary Flow:- 500 m3 / Hr
Flow 1 Meter Head Loss:- 610 m3 / Hr
Normal Flow:- 250 m3 / Hr
Min. Flow for 2% Accuracy:- 8.5 m3 / Hr
Min. Flow for 5% Accuracy:- 7.0 m3 / Hr
Max Working Pressure:- 16 Bar
Max Temperature:- 30°C
Min Reading:- 100 Litres
Max Reading:- 108 m3
Length:- 350mm
4″ Flanged Threaded Water Meter
Connection:- 4″ flange (100mm)
Body:- Coated cast iron case and head
Turbine:- Non-hygroscopic and antimagnetic
Constant / K Factor:– K = 1000.0 (1 pulse per 1000.0 Litres)
Contacting Head Output:- Reed Switch rated at 5 VA
Start Flow:- 2.0m3 / Hr
Max Temporary Flow:- 500 m3 / Hr
Flow 1 Meter Head Loss:- 610 m3 / Hr
Normal Flow:- 250 m3 / Hr
Min. Flow for 2% Accuracy:- 8.5 m3 / Hr
Min. Flow for 5% Accuracy:- 7.0 m3 / Hr
Max Working Pressure:- 16 Bar
Max Temperature:- 30°C
Min Reading:- 100 Litres
Max Reading:- 108 m3
Length:- 350mm
PCD:- 295mm
Flange Fixing Holes:- 12
