SMC SOLENOID VALVE SY9220-5LZD-03
Roll over image to zoom in
৳ 6,000.00৳ 7,500.00 (-20%)
- SY9220-5LZD-03
- Brand: SMC
- Fluid: air
- Operating pressure range: (internal pilot) 0.1 - 0.7MPa
(external pilot) -100kPa to 0.7MPa
(external pilot, pilot pressure range) 0.25 - 0.7MPa - Effective area mm 2 (Cv): body ported 10.6 (0.59);
base mounted 12.6 (0.7) - Coil rated voltage: 24VDC
- Response time (0.5MPa) w/o indicator light andamp;
surge voltage suppressor: 32ms or less - Ambient andamp; fluid temperature: 50 C
- SY9220-5LZD-03
- Brand: SMC
- Fluid: air
- Operating pressure range: (internal pilot) 0.1 – 0.7MPa
(external pilot) -100kPa to 0.7MPa
(external pilot, pilot pressure range) 0.25 – 0.7MPa - Effective area mm 2 (Cv): body ported 10.6 (0.59);
base mounted 12.6 (0.7) - Coil rated voltage: 24VDC
- Response time (0.5MPa) w/o indicator light andamp;
surge voltage suppressor: 32ms or less - Ambient andamp; fluid temperature: 50 C
